SOL-I-BB-M1 – Mecer 1Kw 12V 1x100A Bat GEL includes 360W PWM Solar Charge Controller
R4198,00
SOL-I-BB-M1 – Mecer 1Kw 12V 1x100A Bat GEL includes 360W PWM Solar Charge Controller | 220Vac (Battery: 6 Month Warranty)
Inverter
Battery voltage 12v
In-built battery specification 100ah / 12v
Rated power 1000w
Output voltage 220vac
Output frequency 50/60hz
Output waveform Pure Sine Wave
Charge by a Mains Supply
Rated Voltage 220VAC
Charge Current 10A (MAX)
Solar Input
Maximum photovoltaic voltage (VDC) 25V
Charge Voltage (VDC) 10-25V
Rated Charge Current (A) 30A
Maximum Power (WP) 360WP
Voltage of Overcharge Protection (VDC) 14.2V
Voltage of Overcharge Recovery (VDC) 14.0V
Voltage of Floating Charge (VDC) 13.7V
DC Output
Voltage of High-Voltage Protection (VDC) 16V
Voltage of High-Voltage Recovery (VDC) 15.2V
Voltage of Low-Voltage Recovery (VDC) 12.6V
Voltage of Low-Voltage Protection (VDC) 11V
5VDC USB Output Port 2 UNITS / MAX 2A 2
12VDC Output Port DC Ports (Max 2A)
Starting Temperature of the exhaust fan Ø 45’C
Ambient Temperature for Operation 0-40’C
Ambient Temperature for Storage -25 – +55’C
Operation/storage conditions 0-90%
6 Month Warranty on Battery
